Connekt World 1M Smart Physical Switch

DoublePress · Single-Pole · RGB Status Indicator

Overview

The Connekt World 1M Smart Physical Switch – DoublePress is a momentary, spring-return switch module designed for direct and unambiguous control of a single electrical output. Unlike traditional latching switches, it always returns to a neutral center position, ensuring full consistency between the physical interface and the system state controlled through the app.

The switch can be pressed upward or downward, with each direction directly commanding the output relay. By default, pressing upward turns the output ON, while pressing downward turns it OFF. This logic can be inverted through the Connekt app to match installation requirements.

A semi-transparent square window at the center of the switch houses an integrated RGB LED, providing immediate visual feedback of the current output state while preserving a clean and uniform front appearance.

Operation Logic

• Momentary double-direction control: press up to turn ON, press down to turn OFF.
• Center-return mechanism: the switch always returns to its neutral resting position.
• No selectable modes: behavior is fixed for predictable operation.
• Output inversion: optional inversion of ON/OFF direction via app.
• App-safe design: momentary operation prevents mismatches between physical and software states.

RGB Status Indicator

The integrated RGB LED is located behind the central window and reflects the actual state of the output relay.

• User-configurable ON and OFF colors
• Default colors: green for ON, red for OFF
• Clear state visibility regardless of physical switch position

Timer Control via Smart Cover

When used with a compatible smart cover, the touch button positioned above the switch functions as a toggle timer. Timer duration is configurable through the Connekt app.

• After the countdown expires, the output relay is toggled automatically
• Functions independently of the physical press direction
• Ideal for delayed actions such as scheduled light shutoff

Installation Notes

• Designed for use in Connekt Smart Frames
• Single-pole switching with one internal relay
• Physical switch is always momentary (non-latching)
• Timer function requires a compatible smart cover
